ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange

  • 1
  • 2

Brand Name : HT

Model Number : ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange

Certification : ISO SGS BV TUV

Place of Origin : China

MOQ : 10PIECES

Price : negotiable

Payment Terms : T/T, L/C, Western Union

Supply Ability : 1000PIECES

Delivery Time : 15-30 days

Packaging Details : Wooden cases, pallets, nylon bags or according to the customers' requirements.

Product name : ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange

Standard : ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange

Technique : Cold/Hot Rolled

Type : carbon steel

Supply : China

Contact Now

ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange

ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange

ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange

A105 Flange Weight

15mm (1/2") A105 Carbon Steel Flanges Weight Chart

Standard
Class
Diameter
Bolt Circle Diameter
Number of Bolts
Bolt Size
Diameter of Bolt Hole
AS4087
PN14
95
67
4
M12
14
AS 2129 Flange
Table C
95
67
4
13
14
Table D
95
67
4
13
14
Table E
95
67
4
13
14
Table F
95
67
4
13
14
Table H
114
83
4
16
17
Table J
114
83
4
16
17
ASTM B16.5
ASTM 150
89
60
4
13
16
ASTM 300
95
67
4
13
16
ASTM 600
95
67
4
13
16
ASTM 900
121
83
4
19
22
ASTM 1500
121
83
4
19
22
ISO 7005 (DIN) Flange
PN6
80
55
4
M10
11
PN10
95
65
4
M12
14
PN16
95
65
4
M12
14
PN20
90
60.5
4
M14
16
PN25
95
65
4
M12
14
PN40
95
65
4
M12
14

Grade A105 Carbon Steel Flanges Chemical Composition

ELEMENT
COMPOSITION, %
Carbon
0.35 max
Manganese
0.60-1.05
Phosphorus
0.035 max
Sulfur
0.040 max
Silicon
0.10-0.35
Copper
0.40 max (1)
Nickel
0.40 max (1)
Chromium
0.30 max (1-2)
Molybdenum
0.12 max (1-2)
Vanadium
0.08 max

Carbon Steel A105 Flange Physical Properties
Density (lb / cu. in.)
0.284
Specific Gravity
7.9
Specific Heat (Btu/lb/Deg F - [32-212 Deg F])
0.107
Melting Point (Deg F)
2740
Thermal Conductivity
360
Mean Coeff Thermal Expansion
6.7
Modulus of Elasticity Tension
30
Modulus of Elasticity Torsion
11

Carbon Steel A105 Flange Mechanical Properties
Mechanical Properties
Requirements
Tensile strength,min,psi [MPa]
70000 [485]
Yield strength,min,psi [MPa]
36000 [250]
Elongation, min, %
30
Reductionofarea,min,%
30
Hardness,HB,max
187


Quality ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange for sale

ASME B16.5 ASTM A105 SW/SO/WN/LWN/Blind Flange Images
